waste oil to diesel

Fully automatic pyrolysis plant

Fully automatic pyrolysis plant:
fully automatic pyrolysis plant
Fully automatic pyrolysis plant

DOING group is the first rate manufacturer for fully automatic pyrolysis plant. We are specialized in pyrolysis unit and others waste regeneration machines. We can supply different solutions according different requirements of our customers. Our plants have been exported into over 30 countries and regions; it is popularized with its low price, high quality, long service life, easy operation and simply maintenance.
Fully automatic pyrolysis plant includes waste tyre pretreatment systm, continuous pyrolysis system with continuous feeding and discharge system controled by PLC system. The main part is the continuous pyrolysis system. Fully automatic pyrolysis plant is for processing waste tires into fuel oil and carbon black for recycle use. Due to continuous feeding and discharge system, the Fully automatic pyrolysis plant can keep working without stop, thus to save energy and time. Also PLC control system makes much less labour cost.
Fully automatic pyrolysis plant technical data:
No. Item Specifications
1 Model DY-C-10 DY-C-20 DY-C-30 DY-C-50 DY-C-60 DY-C-80 DY-C-100
2 Cpacity 10T/D 20T/D 30T/D 50T/D 60T/D 80T/D 100T/D
3 Power 35Kw 50Kw 65Kw 80Kw 90Kw 105Kw 120Kw
4 Working type Continuous
5 Reactor deisgn Mutiple reactors (The quantity and size depends on the raw material condition)
6 Rotating Internal rotating
7 Cooling system Recycled waster cooling
8 Reactor material Q245R/Q345R boiler plate
9 Heating method Indireact hot air heating
10 Heating fuel Fuel oil/gas
11 Feedstock Waste tire/plastic/rubber
12 Output Fuel oil, carbon black

Fully automatic pyrolysis plant final product and application:
After processed by fully automatic pyrolysis plant, you can get fuel oil and carbon black. The following are the function of products from Fully automatic pyrolysis plant.

waste plastic pyrolysis plant
Application of continuous model waste tyre pyrolysis plant
