The newest used tyres and plastic recycling machine

Features of The newest used tyres and plastic recycling machine as follows:
1. raw material is cheap and easy to provide
2. 100% wastage tyre recycling is achieved
3. no soil, water or air pollution is observed during and after the process
4. creates economically valuable products out of wastage tyres
5. cost-effective wastage tyre recycling technology in the world
6. it is a 100 % pollution free process, thus making eco-friendly environment
7. the process can be applied to all rubber based materials
8. the system creates an alternate source of energy to replace petroleum products and natural gas
9. system gives the opportunity to governments and local administrations to deal with the wastage tyre problem
10. The process of pyrolysis has duration of 15 to 18 hours, depending on the quantity and size of tyre. During the process different vacuum values are applied in pre-determined temperatures in different phases. Different gases are obtained and the condensed gas is stored as a fuel oil in tank.

As a result of the newest used tyres and plastic recycling machine, we obtain:
1. Fuel oil (40% to 45%)
Through our recycling machine, we obtain fuel oil, which is extensively used for industrial and commercial purposes. The oil has 45% to 55% of the amount of recycled scrap tyres, which are carried with licensed tanker trucks.
2. Carbon black (30% t0 35%)
Carbon black is the main product recycled by pyrolysis process. The amount of recycled carbon black is 30% to 35% (depending on the type of tyres) of the total amount of scrap tyres recycled in the system. Carbon black is used as raw material or as the main ingredient in many industries. The chemical structure of carbon black strengthens, lengthens and improves the coloring features of the materials.

Carbon black produced by pyrolysis process (cbp) is more economical as compared to carbon black produced primarily from petroleum. It is more reasonable to be used as an ingredient in the industries listed mentioned below:
• electric cable jacketing
• conveyor band
• carrier bands
• hose and doormat
• black nylon bag
• rubber additive
• automotive spare parts
• heat isolation
• black colorant in rubber materials
• plastic pipes
• industrial rubber products
• fire fighting

Technical parameter of the newest used tyres and plastic recycling machine
No.	Items	Contents
1	Equipment type	DY-1-6	DY-1-8	DY-1-10
2	Raw material	Waste tyre/plastic	Waste tyre/plastic	Waste tyre/plastic
3	Structural form	Horizontal rotation	Horizontal rotation	Horizontal rotation
4	24-hour Capacity	6 ton	8 ton	10 ton
5	Oil yield	2.7-3.3ton	3.6 -4.4ton	4.5 -5.5ton
6	Operating pressure	Normal	Normal	Normal
7	Material of pyrolysis Reactor	Q245R	Q245R	Q245R
8	Thickness of pyrolysis Reactor	16mm	16mm	16mm
9	Rotate speed of pyrolysis Reactor	0.4turn/minute	0.4turn/minute	0.4turn/minute
10	Total power	19KW	19KW	19KW
11	Mode of cooling	Water cooling	Water cooling	Water cooling
12	Cooling area of condenser	100sqm	100sqm	100sqm
13	Kind of transmission	Internal gear drive	Internal gear drive	Internal gear drive
14	Noise dB(A)	≤85	≤85	≤85
15	Size of Reactor(D×L)	2200×6000	2200×6600	2600×6600
16	Working form	Intermittent operation	Intermittent operation	Intermittent operation
17	Delivery time	20days	20days	20days
18	Weight	27T	30T	35T

Prepared by customer about the newest used tyres and plastic recycling machine
No.	Item	Consumption
1	Coal(for choice)	500kg/day
2	Wood(for choice)	800kg/day
3	Natural gas(for choice)	100-150kg/day
4	Oil(for choice)	300-350kg/day
5	Electricity	244kwh/day
6	Water(recycled)	60㎥ /month
7	Total power	19kw
8	Land area	35m*15m

Fuel oil application from the newest used tyres and plastic recycling machine

Our clients can avail from us premium quality waste tyre and plastic recycling plant that is manufactured employing latest equipment at vendors' end. It scores high on functional life and also exhibits durability and reliability. In addition to this, it is packed using tamper-proof and strong material to facilitate its safe transit.
On offer from us is world class range of Waste tyre and plastic recycling plant that is procured from the vendors of high repute after doing extensive market research. It is known for its high quality, excellent performance and low power consumption. Apart from this, we make sure that these products are delivered within postulated time frame at clients' premises.
